PediTred SA G7
The ultimate in strength and performance.
PediTred® SA (G7) is an architectural entrance grid ideal for high-traffic areas.
This product features serrated aluminum treads for low maintenance care and excellent shoe-cleaning and traction capability.
PediTred SA boasts a 1,000 lb-per-wheel rolling load capacity and rolls back for easy cleaning.
THE PEDITRED/PEDITRED LP PERFORMANCE RATING
-
0.70
-
1000 lb / 750 lb
-
Carpet or abrasive inserts most effective
-
High capacity
-
Carpet inserts most effective
-
Yes
-
Yes
THE PEDITRED BENEFIT
ROLLING LOADS
The industry's strongest grid handles rolling loads up to 1,000 lbs per wheel. Available in 3/4" and 1/2" profiles.
CLEANING
PediTred and PediTred LP roll back for easy cleaning.
INSTALLATION
PediTred and PediTred LP can be either surface mounted or recessed.
RENOVATION-FRIENDLY
PediTred 1/2" deep low-profile is ideal for renovation projects.
Features
Can be recessed or surface mounted
Available in 3/4" (19.1mm) & 1/2" (12.7mm) profiles
Aluminum tread rails
Completely customizable
Slip resistant
For new construction or existing recesses
Building Segments
Aviation & Transportation, Education, Healthcare, Office & Mixed Use, Retail & Hospitality, Senior Living ,Sports & Entertainment
Benefits
Grid system rolls back for easy cleaning
Traps dirt & debris at the door
Excellent shoe-cleaning & traction capability
Certifications
Static Coefficient of Friction Test
Radiant Flux of Floor Covering Test
PediTred Radiant Panel Flammability Test
PediTred Smoke Density Test
Cradle-to-Cradle CertifiedTM Silver
PediTred CDPH 01350 v1.2 Test Certificate
LEED compliant
PVC-free
Indoor air quality pollutant control
Mounting Options
Surface mounted: Tapered aluminum frame, Carpet transition frame, Threshold frame (LP only)
Recessed mounted: Tapered angle frame, Level base frame
Benefits
Grid system rolls back for easy cleaning
Traps dirt & debris at the door
Excellent shoe-cleaning & traction capability
Product Details
Available in 11/16" (17.5mm)
Product weight: 2.67 lbs/sq ft 3.31 lbs/sq ft & 3.39 lbs/sq ft . 1 1/2" (38.1mm) O.C. tread spacing
PediTred G7: 1,000 lbs/wheel rolling load capacity
Has an all aluminum serrated tread surface
Warranty
Two-Year Limited Warranty
Applications
Vestibules, Interior & exterior entries
INSERTS & RAIL FINISHES
Exterior Brush Tread
Rugged polypropylene fibers handle exterior elements. Available in four colors* as denoted.
MonoTuft HD™
Our unique fiber combination including monofilament fibers offers the most aggressive interior carpet insert available. Offered in 21 colors.
Carpet Tread Inserts
* Available in Exterior Brush Tread
† Man made cocoa fibers only available for exterior applications.
Abrasive Tape Inserts
Poured Abrasive Inserts
Rubber & Aluminum Inserts
Rail & Frame Finishes
Due to the differences between monitors, the colors above may vary when specifying. Request color samples. McCrann custom Flooring reserves the right to make design changes or to withdraw any design without notice.
